Isolation Voltage：1500 Vdc
Output Voltage Trim
No minimum load limit
Over Temperature Protection
Input Under Voltage Protection
Output Over Current / Over Voltage / Short Circuit Protection
| Product Series | Package Size (mm) |
Power (W) |
Input Voltage | Output Voltage (Vdc) |
Maximum Output Current (A) |
Efficiency (%) |
Product Model | Specification Download |
|---|---|---|---|---|---|---|---|---|
| Ruggedized DC-DC | 1/16 Brick | 50 | 9-40 | 5 | 10 | 88 | VI50S18S05xNS-G | |
| Ruggedized DC-DC | 1/16 Brick | 50 | 9-40 | 12 | 4.17 | 90.5 | VI50S18S12xNS-G | |
| Ruggedized DC-DC | 1/16 Brick | 50 | 9-40 | 24 | 2.08 | 90.5 | VI50S18S24xNS-G | |
| Ruggedized DC-DC | 1/16 Brick | 50 | 9-40 | 28 | 1.79 | 90.5 | VI50S18S28xNS-G |
